Highly Stable Inclinometer Switch with 0.05 Deg Long Term Stability
Product Description:
LCA331A series a low cost tilt switch developed by RION for application like level safety alarming and platform level monitor and alarm. Alarm threshold value is pre-setable. when the inclination exceed set alarm value, it will output switch output signal(output voltage=input voltage), to drive the solenoid valve hydraulic system or drive buzzer or alerming light for the safety of platform. Its main function is to monitor and alarm the(dual axis or single axis) inclination of platform automatically. LCA331A series tilt switch has high accuracy bubble for zero reference, LED alarming function.
Features:
- Single/dual axis
- RS232 set alarm angle
- Switch output
- high anti-vibration>2000g
- direct lead cable
- DC 9～36v input
This Inclinometer Switch is a reliable and accurate Tilt Angle Detector, also known as an Inclination Sensor. It has a fast response time of 0.2s, a long-term stability of 0.05 Deg, and a power on time of 0.1S. It operates within a wide working temperature range of -40~+85℃, making it suitable for various applications that require precise angle detection.
Technical Parameters:
LCA331&LCA332 | CONDITIONS | PARAMETER | UNIT |
| Measure range | | ±15 | ° |
| Measure axis | | X Y | Axis |
| Resolution | | 0.05 | ° |
| Measure accuracy | | 0.1 | ° |
| Long-term stability | | 0.05 | ° |
| Zero temp. coeffiecient | -40～85℃ | ±0.01 | °/℃ |
| Temp.Sensitivity coefficient | -40～85℃ | ≤100 | ppm/℃ |
| Power on time | 0.1 | S |
| Response time | 0.2 | s |
| Electromagnetic compatibility | According to EN61000 and GBT17626 |
| MTBF | ≥50000hours/times |
| Insulation Resistance | ≥100MΩ |
| Impact resistance | 100g@11ms,3 axial direction (half sinusoid) |
| Anti-shock | 10grms,10～1000Hz |
| Protection grade | Direct lead IP67; Aviation plug IP65 |
| Cables | 1m, durable, grease proof, wide temperature, shield cable, 4*0.4 mm2 |
| Weight | 140g(without cable) |
Applications:
- Bridge & dam detection
- Underground drill posture navigation
- Engineering vehicles automatic leveling
- Shield pipe jacking application
- The intelligent excavator / crane / cranes / pile driver / drill machine / special vehicles / mine car / track car / fire truck / aerial vehicles / bridge machine
